A333 GR.3 Carbon Steel Yeeb Nkab
A333 Qib 3 Alloy Tubes yog tsim los siv cov khoom zoo zoo raw khoom los ntawm cov neeg muag khoom ntseeg siab thiab ntseeg siab hauv kev lag luam. Cov khoom no tau txais ntau yam kev kho cua sov thiab cov txheej txheem kuaj xws li kev sim cuam tshuam, kuaj hydrostatic, kuaj tensile thiab tsis muaj hluav taws xob kuaj xyuas kom paub tseeb tias lawv ua raws li cov yam ntxwv.
A333 GR.3 yeeb nkab yog cov yeeb nkab uas tsis tshua muaj siab carbon steel uas ua tau raws li cov kev cai ntawm ASTM A333 specifications. Nws yog carbon hlau alloy ntawm hlau, manganese thiab silicon.
A333 GR.3 carbon steel yeeb nkabmuaj cov yam ntxwv ntawm siab elasticity thiab nruab nrab tensile lub zog. Nws yog tsim rau kev sib sau txias, kub ua thiab vuam. Nws lub zog tensile yog kwv yees li 450 MPa thiab lub zog tawm los yog 240 MPa.
A333 GR.3 low-temperature alloy yeeb nkab yog seamless steel yeeb nkab nrog zoo toughness thiab ductility hauv qab -45 degree thiab corrosion kuj thiab qaug zog kuj. Yog li ntawd, A333 GR.3 cov yeeb nkab uas tsis muaj qhov kub thiab txias yog tsim rau kev lag luam tshuaj lom neeg, roj av, kev siv hluav taws xob tsawg xws li cov roj ntsha thiab cov kav dej txias.
Ua Haujlwm Tiv tauj peb:sales@gneetube.com
A333 Pawg 3 Alloy Cryogenic Tube Specification:
| Specifications | ASTM A 333, ASME SA 333 |
| Qhov Loj | 1/2 "NB to 36" NB |
| Sab nrauv Dimensions | 19.05mm -114.3 hli |
| Phab ntsa Thickness | 2. 0mm-14 hli |
| Hom | Seamless / Welded |
| Teem caij | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, Tag nrho cov sij hawm |
| Ntev | max 16000 mm |
| Qib | Qib 3 |
A333 Pab Pawg 3 Carbon Alloy Steel Yeeb Nkab Cov Khoom Siv Tshuaj:
|
Qib |
C. max |
Si min |
Mn |
P |
S |
|
Gr. 3 |
0.19 |
0.18-0.37 |
0.31-0.64 |
Tsawg dua lossis sib npaug rau 0.025 |
Tsawg dua lossis sib npaug rau 0.025 |
A333 Pawg 3 alloy seamless yeeb nkab txhua yam khoom:
|
Qib |
Tensile zog Rm |
Yield zog YS |
Enlongation A (％) |
|
Gr. 3 |
450 |
240 |
Ntau dua lossis sib npaug li 15 |
LTCS A333 Gr 3 Yeeb Nkab Phab Ntsa Thickness
| Phab ntsa Thickness | Qib 3 | ||
| hauv. | mm | Ntev | Transverse |
| 5/16 (0.312) | 8 | 30 | 20 |
| 9/32 (.281) | 7.2 | 28 | 19 |
| 1/4 (.250) | 6.4 | 27 | 18 |
| 7/32 (.219) | 5.6 | 26 | |
| 3/16 (.188) | 4.8 | 24 | |
| 5/32 (.156) | 4 | 22 | |
| 1/8 (.125) | 3.2 | 21 | |
| 3/32 (.094) | 2.4 | 20 | |
| 1/16 (.063) | 1.6 | 18 | |
A333 GR.3 carbon steel yeeb nkab
Gnee Company cov khoom
FAQ
Q: Cov khoom siv ntawm koj lub Hoobkas yog dab tsi?
Teb: Peb lub Hoobkas muaj cov cuab yeej ua haujlwm siab tshaj plaws, xws li cov khoom kub dov cov kab ntau lawm, txias-dov seamless steel yeeb nkab ntau lawm cov cuab yeej, txias-dov coil ntau lawm cov cuab yeej, customized steel txiav cov cuab yeej, ultrasonic kuaj tshuab, lub ntsiab analyzers, thiab txheej. thickness ntsuas ntsuas, thiab lwm yam., ua rau peb cov khoom zoo dua thiab ntau lawm efficiency siab dua.
Q: Koj ua li cas kom ntseeg tau qhov zoo ntawm koj cov khoom?
A: Tag nrho cov khoom yuav tsum tau soj ntsuam peb zaug thaum tag nrho cov txheej txheem tsim khoom, suav nrog ntau lawm, txiav thiab ntim. Daim ntawv tshaj tawm kev tshuaj xyuas lub Hoobkas yog muab nrog cov khoom. Yog tias tsim nyog, kev tshuaj xyuas thib peb xws li SGS tuaj yeem lees txais.
Q: Kuv tuaj yeem ntseeg koj li cas?
A: Peb ntseeg tias kev ncaj ncees yog lub neej ntawm peb lub tuam txhab. Peb zoo siab tos txais koj tuaj xyuas peb lub Hoobkas hauv Henan, Tuam Tshoj, thiab tshuaj xyuas peb lub tuam txhab, lub Hoobkas thiab cov khoom lag luam los ntawm kev yees duab, tshaj tawm hauv xov tooj cua, thiab lwm yam.
