API 5CT L80 Casing Thiab Tubing

Name: Tuam Tshoj API 5CT L80 Casing Thiab Tubing Chaw tsim tshuaj paus Hoobkas - Gnee Steel
Brand: GNEE
SKU: 305998804

API 5CT L80 Casing thiab Tubing yog ib hom tshwj xeeb ntawm cov yeeb nkab siv rau cov roj zoo drilling, uas yog siv rau hauv cov roj thiab roj extraction teb.Thiab nws suav nrog qib L80-1, L80 9Cr, L80 13Cr.

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

API 5CT L80 Casing thiab Tubing

yog dab tsiAPI 5CT L80 Casing yeeb nkab thiab Tubing yeeb nkab?

API 5CT L80 Casing yeeb nkab thiab Tubing yeeb nkabtxhawb nqa lub qhov dej ntawm cov roj thiab cov roj qhov dej, ua kom cov drilling du thiab ntev - lub sij hawm ntau lawm kev nyab xeeb, thiab tsim cov qauv tseem ceeb ntawm lub qhov dej.Cov khoom ua raws li API SPEC 5CT tus qauv.L80 yog ib qho ntawm 10 qib steel uas tau teev tseg los ntawm API 5CT tus qauv, uas suav nrogL80-1thiab siab -kev ua tau zoo alloy steels xws liL80-9CrthiabL80-13Cr.Qhov txawv ntawm peb hom hlau no nyob hauv lawvcov ntsiab lus chromium.L80 9Cr muaj8-10%chromium thiab L80 13Cr muaj12-14%chromium.

API 5CT L80 oilfield casing yeeb nkab Specification

Txuj: API 5CT

Qib: L80-1, L80 9Cr, L80 13Cr

Qib Specification: PSL1, PSL2 thiab PSL3

Hom: Seamless OCTG

Ntev: R1, R2, R3

Tshuag Muaj: Yog

API 5CT L80 Casing thiab Tubing Applications

Downhole casing thiab tubing nyob rau hauvroj thiab roj qhov dej, kev txhawb nqa lub wellbore, cais cov tsim, thauj cov roj thiab roj.

yam ntxwv

Mechanical kev ua tau zoo:

Lub zog tawm los ntawm L80 yog nruj me ntsis txwv rau552-655 MPa, uas yog nruab nrab thiab tsis siab dhau lossis qis dhau, thiab yog tsim tshwj xeeb kom haum rau kev tsim siab ntawm nruab nrab thiab sib sib zog nqus roj thiab roj qhov dej.The API tus qauv nruj me ntsis txwv cov hardness rautsis ntau tshaj 22 HRC. Nws yog ib txwm sulfide- tiv thaiv kev ntxhov siab- qib steel tawg thiab tuaj yeem siv rau hauv cov roj av acidic uas muajH₂S. L80 ua tiav qhov sib npaug zoo ntawm lub zog, tawv, tawv, thiab cov kua qaub ua haujlwm, ua rau nws nyiam qib steel rau nruab nrab - qhov dej tob thiab cov dej acidic.

Corrosion kuj:

L80-1: Txheem carbon steel, haum rau cov leej faj zoo tib yam-dawb, qis-cov roj thiab cov qhov dej zoo, cov nqi ua haujlwm siab.

L80 9Cr thiab 13Cr: Chromium alloy, tiv taus CO₂ thiab H₂S acid corrosion, haum rau cov dej corrosive heev, leej faj- muaj cov qhov dej, thiab qhov dej kub hauv qhov dej.

Cov yam ntxwv ntawm kev ua haujlwm:

Tshwj xeeb tsim rau cov roj casing thiab tubing, txhawb nqa lub qhov dej, cais qhov tsim, thiab thauj cov roj thiab roj.Suitable rau nruab nrab - qhov dej tob, acidic qhov, coalbed methane qhov dej, geothermal qhov dej, siab - dej siab los yog roj txhaj qhov dej.Highly adaptable mus rau ntau yam xov xwm puag ncig, ntev thiab ntev. siab-kawg xov tshwj xeeb, muab kev sib khi zoo heev thiab kev sib txuas ruaj ntseg.

roj yeeb kev qhia txog xim

L80-1: Ib kab liab thiab ib kab xim av.

L80 9Cr: ib lub paj liab, ib lub xim daj thiab ob lub paj daj.

L80 13Cr: ib kab liab, ib kab xim av thiab ib kab daj daj.

casing yeeb nkab Length range

R1: 4.88 rau 7.62 m

R2: 7.62 txog 10.36 m

R3: 10.36 - 14.63 m

API 5CT L80 casing thiab tubing Cov Kev Xav Tau Zoo thiab Kev Tshuaj Xyuas

Zoo Zoo:

Sab hauv thiab sab nrauv ntawm lub casing thiab coupling nto yuav tsum tsis txhob muaj qhov tsis xws luag xws li folds, hairline tawg, delamination, tawg, dov creases, thiab nplai. Kev tshem tawm ib feem ntawm qhov tsis xws luag yog tso cai, tab sis qhov tob yog nruj me ntsis txwv.

Kev kuaj lub cev ua haujlwm:

Kev ntsuam xyuas flattening, tensile test, hydrostatic tests, hardness tests, and impact tests, to verify it mechanical integrity and pressure-bearing capacity.

Kev xeem tshuaj muaj pes tsawg leeg:

Kev txheeb xyuas meej ntawm cov ntsiab lus ntawm cov ntsiab lus xws li carbon, sulfur, phosphorus, thiab chromium yog ua los xyuas kom meej tias cov ntaub ntawv ua tau raws li cov qauv teev tseg.

Ntim thiab Ntau Lawm

Ntim:

Cov khoom tsim hauv tsev feem ntau yog bundled nrog steel hlau lossis steel strapping. Txhua lub yeeb nkab threaded kawg yuav tsum haum nrog lub nplhaib tiv thaiv kom tsis txhob muaj kev puas tsuaj thaum thauj thiab khaws cia.

API 5CT L80 Packaging Image

API 5CT L80 OCTG casing txheej txheem ntau lawm

Ib qho tsim nyog API 5CT L80 casing yuav tsum muaj ntau yam txheej txheem, suav nrog kev nruam nruam ntawm cov pob zeb, tho thiab dov, quenching thiab tempering tshav kub kho, kev kho deg, thiab kev soj ntsuam tag nrho.

GNEE API 5CT L80 OCTG Pipe Test Equipments

test

GNEE API 5CT L80 Oil Well Casing Pipe daim ntawv pov thawj

certification

FAQ

1. API 5CT L80 yog dab tsi?

API 5CT L80 yog ib homOCTG seamless steel yeeb nkabrau roj casing thiab tubing, ua raws li API 5CT thoob ntiaj teb tus qauv. Nws yog quenched thiab tempered rau ruaj khov mechanical kev ua tau zoo.

2.Cov xov twg koj txhawb nqa?

Peb muab Xov Round Round, Ntev Round Thread, Buttress Thread thiab hwm kev sib txuas tshwj xeeb raws li xav tau.

3.Koj puas muab lub Hoobkas kuaj daim ntawv pov thawj?

Yog lawm, tsab ntawv ceeb toom tshuaj xyuas thiab cov ntaub ntawv pov thawj API tuaj yeem muab tau.

Cim npe nrov: api 5ct l80 casing thiab tubing, Tuam Tshoj api 5ct l80 casing thiab tubing manufacturers, lwm tus neeg, Hoobkas
