API 5CT K55 BTC Casing Pipe
API 5CT K55 BTC Casing Pipe yog dab tsi?
API 5CT:Cov txheej txheem thoob ntiaj teb tau teeb tsa los ntawm American Petroleum Institute rau casing thiab tubing siv hauv cov roj thiab cov qhov dej.
K55 Qib:Qib nruab nrab -lub zog carbon steel. Thaum nws lub zog tawm los (55,000–80,000 psi) zoo ib yam rau qib J55,K55 muaj lub zog tensile tsawg dua (Ntau dua lossis sib npaug rau 95,000 psi). Qhov no ua rau nws muaj kev nyab xeeb rau cov qhov tob tob uas qhov hnyav ntawm cov yeeb nkab hlua yog qhov tseem ceeb.
BTC (Buttress Xov Txuas Txuas):Ib tug trapezoidal (lub taub qab-zoo li tus) xov tsim. Nws yog engineered los muab siab axial tensile lub zog, ua rau nws zoo heev rau ntev, hnyav casing hlua. Nws tseem nta "yooj yim stabbing" thaum lub sij hawm sib dhos txheej txheem.
Casing Tube:Muab tso rau hauv lub borehole kom stabilize lub qhov dej, cais cov formations sib txawv, tiv thaiv lub cev qhuav dej, thiab tiv thaiv dej hauv av los ntawm kev sib kis.
Xav tau tag nrho cov neeg kho tshuab specs thiab kev sib tsoo siab rau K55 BTC?Download tau cov ntaub ntawv Technicalrau koj cov ntaub ntawv engineering.
API 5CT K55 BTC Specification Chart
Cov lus hauv qab no muab qhov ntev geometric thiab cov khoom siv kho tshuab rau K55 BTC specifications.
Dimensions thiab Phab Ntsa Thickness (Common Size)
| Sab nraud txoj kab uas hla (OD) | Nominal Nyhav | Phab ntsa Thickness | Sab hauv Diameter (ID) | Drift Diameter |
| ntiv tes (mm) | lb/ft (kg/m) | ntiv tes (mm) | ntiv tes (mm) | ntiv tes (mm) |
| 4-1/2" (114.3) | 11.60 | 0.250 (6.35) | 4.000 (101.6) | 3.875 (98.4) |
| 5-1/2" (139.7) | 15.50 | 0.275 (6.98) | 4.950 (125.7) | 4.825 (122.6) |
| 17.00 | 0.304 (7.72) | 4.892 (124.3) | 4.767 (121.1) | |
| 7" (177.8) | 23.00 | 0.317 (8.05) | 6.366 (161.7) | 6.241 (158.5) |
| 26.00 | 0.362 (9.19) | 6.276 (159.4) | 6.151 (156.2) | |
| 9-5/8" (244.5) | 36.00 | 0.352 (8.94) | 8.921 (226.6) | 8.765 (222.6) |
| 40.00 | 0.395 (10.03) | 8.835 (224.4) | 8.679 (220.5) | |
| 13-3/8" (339.7) | 54.50 | 0.380 (9.65) | 12.615 (320.4) | 12.459 (316.5) |
| 61.00 | 0.430 (10.92) | 12.515 (317.9) | 12.359 (313.9) |
API 5CT Yeeb Nkab Dimensional Tolerances
| Yam khoom / Parameter | Tolerance Yuav Tsum Tau | Lus hais |
| Sab nraud txoj kab uas hla (D) | ||
| - Rau D<4−1/2" (114.3mm) |
±0.79 mm ( ±0.031"± ) |
Siv rau cov kav dej me me |
| - Rau D Ntau dua lossis sib npaug rau 4−1/2"(114.3 hli) | +1.00% / -0.50% | Standard rau ntau qhov ntau thiab tsawg |
| Phab ntsa Thickness (t) | -12.5% | Tsis muaj kev txwv tshwj xeeb; tswj los ntawm qhov hnyav |
| Qhov hnyav (Mass) | ||
| - Ib Ntev | +6.5% / -3.5% | Ib leeg yeeb nkab kam rau ua |
| - Carload (Ntau) | -1.75% | Ua siab ntev rau kev txiav txim loj batch |
| Ovality | Muaj nyob rau hauv OD kam rau ua | Kev nruj rau qhov kawg 1.5m ntawm cov yeeb nkab kawg |
Casing Length Ranges
API 5CT faib cov casing rau hauv peb qhov ntev.Ntau yam 3yog qhov feem ntau rau thoob ntiaj teb K55 BTC exports.
| Ntev Ntau | Ntev (ft) | Ntev (m) |
| Ntau yam 1 | 16.0 - 25.0 | 4.88 - 7.62 |
| Ntau yam 2 | 25.0 - 34.0 | 7.62 - 10.36 |
| Ntau yam 3 | 34.0 - 48.0 | 10.36 - 14.63 |
K55 Mechanical Properties
| Khoom | Imperial (psi) | Metric (MPa) |
| Min. Yield zog | 55,000 | 379 |
| Max. Yield zog | 80,000 | 552 |
| Min. Tensile zog | 95,000 | 655 |
| Phab ntsa Thickness kam rau ua | -12.5% | -12.5% |
Chemical Composition (%)
| Phosphorus (P) | Sulfur (S) | Cov pa roj carbon (C) | Manganese (Mn) |
| Tsawg dua lossis sib npaug li 0.030 | Tsawg dua lossis sib npaug li 0.030 | Mfr. Kev txiav txim siab (Typ. 0.20-0.40) | Mfr. Kev txiav txim siab (Typ. 1.00-1.50) |
Hlau Qib Identification (K55)
Raws li API 5CT, xim rau tsev neeg "55" yogNtsuab Ntsuab.
| Cheebtsam | Xim qauv |
| Yeeb Nkab Bands | Ob Lub Paj Ntsuab Ntsuab |
| Kev sib txuas | Painted kiag li Bright Green |
K55 BTC Inspection
| Kev tshuaj xyuas qeb | Yam khoom tseem ceeb | Lub Hom Phiaj |
| Khoom siv | Tensile & Yield Test | Tshawb xyuas K55 lub zog |
| Lub cev | Drift Test | Xyuas kom meej qhov nkag hauv |
| Xov | BTC Gauging & Daim duab peb sab Mark | Xyuas kom muaj kev sib koom ua ke |
| Kev ncaj ncees | EMI / Ultrasonic (NDT) | Nrhiav zais qhov flaws |
| Siab | Hydrostatic Test | Paub meej tias leak- pov thawj kev ua haujlwm |
| ID | 2 Kab Ntsuab Ntsuab | Tiv thaiv kom tsis txhob siv qib tsis raug |
GNEE API 5CT K55 BTC Casing Pipe txheej txheem kab
GNEE API 5CT K55 BTC OCTG Casing Pipe test equipments
GNEE API 5CT K55 BTC Roj zoo casing yeeb nkab daim ntawv pov thawj
FAQ
Qhov txawv ntawm J55 thiab K55 yog dab tsi?
A: Lawv sib koom tib lub zog tawm los, tab sisK55 muaj zog tensile ntau dua(95 ksi vs . 75 ksi). K55 muaj kev nyab xeeb dua rau cov hlua hauv qab nruj dua.
Vim li cas thiaj xaiv BTC hla STC/LTC?
A: BTC (Buttress)muaj superior axial tensile lub zog thiab tuaj yeem txhawb ze li 100% ntawm cov yeeb nkab lub cev load. Nws yog qhov zoo dua rau qhov dej tob thiab loj - txoj kab uas hla.
Puas yog K55 haum rau H2S ib puag ncig?
A: Tsis muaj.Nws yog tus qauv carbon steel. Rau kev pabcuam qaub, koj xav tau qib L80, C90, lossis T95.
Koj puas txhawb Third-Party Inspection (TPI)?
A: Yog, peb txais tosSGS, BV, lossis Intertektxhawm rau txheeb xyuas EMI, UT, thiab Hydrostatic tests ntawm peb qhov chaw.
Qhov siab tshaj plaws qhov tob rau K55 yog dab tsi?
A: Feem ntau rau qhov dej mus txog2,000-3,000 m, nyob ntawm OD thiab phab ntsa thickness.
